Complete cooling & freezing installations

IMAG0007.jpg IMG_0165.jpg IMG_0166.jpg IMG_0177.JPG nixel.gif

Description / remarks:

Used, very special low temperature DWM/Copeland/Helpman storage/freezing installation (cascade system) and consists of the following main components:

  • Cascade central compressor unit, consists of:
    1 x semi-hermetic DWM low pressure compressor, working with refrigerant R23 at evaporating temperature of -68°C
    2 x semi-hermetic high pressure compressors, working with refrigerant R404A at evaporating temperature -30°C
  • 2 x Helpman single sided blowing low temperature evaporators with each 2 pieces ventilators of 750W, electrical defrost, air flow 10.400m3/h, dimensions 210 x 110x 70 cm and weight 110kg
  • 1 x Helpman double sided blowing evaporator for the production room(sluice) -20°C ambient temp. with 3 ventilators of 250W, electrical defrost, air flow 5.400m3/h, dimensions 345 x 170 x 59cm, weight 325kg with a cooling capacity of 28kW at evaporating temperature of -30°Cl
  • 1 x Helpman air-cooled condenser with copper/seawater resistant fin coils
  • Switch-board
  • Under-pressure and over-pressure valves

Mentioned cooling capacity is with the refrigerant R23+R404a at -68°C/-30°C, -30°C/+40°C.



This installation is suitable for a freeze storage of approx. 600m3with a storage temperature of -60°C to -65°C, very suitable for tuna storage.


Cooling capacity:
14 kW/4 tons
Number of cooling circuits:
2
Type of refrigerant:
R23+R404A
Voltage:
380 V V
Absorbed power:
28 kW
Year of Manufacture:
2001


IMG_1587_25.3_koelinstalatie.jpg IMG_1588_25.3_koelinstalatie.jpg saladearriba-25.3kw.jpg IMG_8761-2-25.3kw.inst.jpg nixel.gif

Description / remarks:

Used, very special low temperature Bitzer storage/freezing installation (cascade system), suitable for very low storage temperatures of -60°C/-65°C and consists of the following main components:

Mentioned cooling capacity is with the refrigerant R23/Ammonia R717 at -68°C/-33°C



This installation is very suitable for freezing tuna, for example, where high quality product is required. For frozen storage approx. 2.000 m3 with two units.

Note: The unit must be connected with the cascade condenser to an ammonia installation at -30°C/-40°C.


2 in stock
Cooling capacity:
25.3 kW/7 tons
Type of refrigerant:
R23/R717
Voltage:
400 V
Absorbed power:
9,1 kW
Year of Manufacture:
2004
Dimensions (LxWxH):
255 x 197 x 196 cm
Weight (kg):
1.600 kg


IMG_8756_51k.koelinstalatie.jpg IMG_8757_51k.koelinstalatie.jpg IMG_8759_51k.koelinstalatie.jpg nixel.gif nixel.gif

Description / remarks:

Used, very special low temperature Bitzer storage/freezing installation (cascade system), suitable for very low storage temperatures of -60°C/-65°C and consists of the following main components:

Mentioned cooling capacity is with the refrigerant R23/Ammonia R717 at -68°C/-33°C



This installation is very suitable for freezing tuna or storing tuna, where high quality product is required. For freezing tuna, a maximum of 800kg/h  of product can be achieved with two units. For frozen storage approx. 4,000 m3 with two units.

Note: The unit must be connected with the cascade condenser to an ammonia installation at -30°C/-40°C.


2 in stock
Cooling capacity:
51 kW/15 tons
Type of refrigerant:
R23/R717
Voltage:
400 V
Absorbed power:
19 kW
Year of Manufacture:
2004
Dimensions (LxWxH):
263 x 217 x 233 cm
Weight (kg):
2.000 kg


Foto 1 -Orizon West INK-2307-60kw vriesinst..jpg
Foto 1 -Orizon West INK-2307-60kw vriesinst..jpg Foto 2 -Orizon West INK-2307-60kw vriesinst..jpg Foto 3 - Orizon West INK-2307-60kw vriesinst..jpg Foto 4 - Orizon West INK-2307-60kw vriesinst..jpg Foto 5 - Orizon West INK-2307-60kw vriesinst..jpg

Description / remarks:

Used complete Bitzer/Güntner freeze/pump installation build in a container. This in very good condition complete freeze pump installation is composed of the following main components:

  • Bitzer screw piston package opentype ASNA 7471-K
    1 piece GEA/Grasso two stage piston compressor type RC4212 (direct driven)
  • MEZ 55kW E-motor 3000 RPM
  • Low 1 pressure separator, brand LCB, volume 480Ltr with 2 pieces Witt liquid pumps
  • Eco-tank -15°C
  • 1 piece Güntner air-cooled condenser type S-AGVH-090.2a/2-NO
  • Complete control cabinet with PLC
  • All necessary control stations, stop valves, liquid valves, floats with brands such as Danfoss, Parker, Witt
  • All required pressure test certificates

Mentioned cooling capacity is with the refrigerant R717/ammonia at -35°C/+40°C at 3000RPM.

Capacity with frequency controller  60Hz 3600 RPM approx. 73kW


Cooling capacity:
60 kW/17,6 tons
Type of refrigerant:
R717/Ammonia
Voltage:
400 V
Year of Manufacture:
2006
Dimensions (LxWxH):
640 x 240 x 240 cm


IMG_9927_83kw.koelinst.jpg IMG_9926_83kw.koelinst.jpg IMG_9925_83kw.koelinst.jpg IMG_9944_83kw.koelinst.jpg IMG_9951_83kw.koelinst.jpg

Description / remarks:

Used and in very good maintained condition (always maintained by GEA) storage freezing installation, brand Bitzer/Goedhart. This storage freezing installation will be composed of the following main components:

  • 1 piece Bitzer screw package type HSN 7471-75-40R
  • Bitzer screw package is equipped with oil separator, air-cooled oil cooler, closed intercooler for subcooling liquid coupled to the eco. compressor, Bitzer liquid tank of 180L
  • Suction manifold with suction filter
  • Manometer set low/high pressure with all necessary safety devices
  • Complete control box with Eliwell step controller
  • 4 pieces Goedhart VCI-B-82508EF freeze storage evaporators with electric defrost
  • Cabero air-cooled condenser type ACHSD099MB / 2L-26D, year of 2016

Mentioned cooling capacity is with the refrigerant R404a/R507 at -30°C /+40°C.

This installation is suitable for a deep-freeze storage of approx.. 4000m storage space with a storage temperature of -20°C.


Cooling capacity:
83 kW/24 tons
Number of cooling circuits:
1
Type of refrigerant:
R404A/All Freon
Amount of refrigerant / circuit:
99 kg
Voltage:
400 V
Absorbed power:
60 kW
Year of Manufacture:
2005/2016


IMG_1433_97kw.rooftop.jpg IMG_1435_97kw.rooftop.jpg IMG_1434_97kw.rooftop.jpg IMG_1440_97kw.rooftop.jpg IMG_1437_97kw.rooftop.jpg

Description / remarks:

Used roof top unit, brand Lennox, type FCK 100N. This in very good condition roof top unit is equipped with the following main components:

  • 2 pieces scroll compressors
  • 1 piece inside-/centrifugal ventilator (5,5kW/833 RPM)
  • 3 pieces outside ventilators (each 3,75kW/1000RPM)
  • Climatic 2 controller
  • Nominal airflow 20.000m3/h
  • Noise level 91dB(A)

Mentioned cooling capacity of 97kW is with 25% fresh air, 35°C DB out , 27°C in with a COP 2.


Cooling capacity:
97 kW/29 tons
Number of cooling circuits:
2
Type of refrigerant:
R407C
Amount of refrigerant / circuit:
13,4 kg
Voltage:
400 V
Year of Manufacture:
2004
Dimensions (LxWxH):
379 x 226 x 150 cm
Weight (kg):
1.280 kg


100kw_inst._IMG_8832.JPG 100kw_inst._IMG_8838.JPG IMG_8842.JPG 100kw_inst._IMG_8851.jpg nixel.gif

Description / remarks:

Used, in very good condition complete Bitzer/Goedhart cooling/freezing combination (very suitable for 0°C, -10°C, -20°C storage temperatures) and consists of the following main components:

Mentioned cooling capacity of 100kW is with the refrigerant R507 at evaporating temperature of -30°C.
Cooling capacity at an evaporating temperature of -10°C is 248kW.


Cooling capacity:
100 kW/29 tons
Type of refrigerant:
R507
Voltage:
400 V
Absorbed power:
75 kW
Year of Manufacture:
2004


12_INK-2115-112kw. koelcentrale.jpg
12_INK-2115-112kw. koelcentrale.jpg 10_INK-2115-112kw. koelcentrale.jpg IMG_1640-112kw. koelcentrale.jpg 33_INK-2115-112kw. koelcentrale.jpg 28_INK-2115-112kw. koelcentrale.jpg

Description / remarks:

Used complete Bitzer/ Searle/GEA cooling plant-/installation. This in very good condition complete cooling plant is composed of the following main components:

  • Bitzer piston package consists of
    1 piece Bitzer piston compressor type 6H-35.2Y (frequency controlled at 60Hz)
    1 piece Bitzer piston compressor type 4G-20.2Y
    Oil separator, Vertical liquid tank, high/low pressure gauges with all necessary safety devices
  • 3 pieces Searle/GEA dual-discharge blowing cooling-/freezing evaporators type LSR122-64-4D-EL, each with air volume 3,6m3/s, fin spacing 4mm, electrical defrost
  • 2 pieces Searle/GEA dual-discharge blowing cooling-/freezing evaporators type DSR100-4L each with air volume 1,7m3/s, fin spacing 4mm, electrical defrost
  • 1 piece Searle/GEA one-sided blowing cooling evaporator type DSR100-4L with air volume 2,7m3/s, fin spacing 4mm, electrical defrost
  • 1 piece Searle/GEA air-cooled condenser type MEC234-N604D AL
  • Complete control cabinet with Danfoss frequency controller

Mentioned cooling capacity of 112kW is with the refrigerant R404 at -8°C/+45°C.


Cooling capacity:
112 kW/32.94 tons
Type of refrigerant:
R404A/All Freon
Voltage:
400 V
Year of Manufacture:
2011


40_INK-2115.Vriesinstallatie-138kw.jpg 63_INK-2115.Vriesinstallatie-138kw.jpg 47_INK-2115.Vriesinstallatie-138kw.jpg 61_INK-2115.Vriesinstallatie-138kw.jpg 48_INK-2115.Vriesinstallatie-138kw.jpg

Description / remarks:

Used complete GEA/Grasso/Goedhart storage freezing pump installation. This in very good condition complete freezing installation is composed of the following main components:

Mentioned cooling capacity of 138kW is with the refrigerant R717/ammonia at -32°C/+30°C at 1000RPM.


Cooling capacity:
138 kW/40.58 tons
Type of refrigerant:
R717/Ammonia
Voltage:
400 V
Year of Manufacture:
2000


installationIMG_2197.jpg installationIMG_2199a.jpg installationIMG_2202.jpg installationIMG_2210a.jpg installationIMG_2213.jpg

Description / remarks:

Used and in condition as new (only 1 year in production) complete Bitzer 2-stage freeze-pump installation built on a steel frame and consists of the following main components:

  • 3 pieces low pressure (booster) screw compressors open type OSKAB 7471 with each a 30kW E-motor
  • 2 pieces high pressure screw compressors open type OSKA 7451 with each a 55kW E-motor
  • 2 x oil separator 881 Ltr for the low and high pressure side
  • Water cooled oil cooler type plate heat exchanger brand Alfa Laval coupled to an air-cooled Güntner dry cooler type GFH 0678/2N
  • Horizontal low pressure separator 640 Ltr -40°C with 2 pieces Hermetic Cam 1/3 NH3 liquid pumps (combined with the intermediate pressure separator)
  • Horizontal intermediate pressure separator 640Ltr -6°C coupled to a plate cooler/ heat exchanger for natural circulation, ± 130kW to be used for glycol cooling if necessary (combined with the low pressure separator)
  • Air-cooled condenser or evaporating condenser at choice
  • Custom made control box with new Siemens PLC/Simatic touchscreen
  • All necessary certificates for PED
  • Cool technical and electrical drawings
  • Custom made Software

Mentioned cooling capacity of is with the refrigerant R717 at -40°C/ +40°C.


Cooling capacity:
140 kW/41 tons
Number of cooling circuits:
1
Type of refrigerant:
NH3 Ammonia
Voltage:
400 V
Absorbed power:
100 kW
Year of Manufacture:
2006
Dimensions (LxWxH):
600 x 180 x 238 cm
Weight (kg):
± 5500 kg


IMG_2444cod.unit165kW.jpg IMG_2445cod.unit165kW.jpg IMG_2446cod.unit165kW.jpg IMG_2447cod.unit165kW.jpg IMG_2448cod.unit165kW.jpg

Description / remarks:

Used complete Daikin condensing unit type ERAD-170 E-SS012 for outdoor application. This in new condition condensing unit is equipped with:

  • Daikin mono screw compressor type HSA312QS6YA (400/460V, 50/60Hz) with stepless capacity control
  • Control box

Mentioned cooling capacity is with the refrigerant R134a at an evaporating temperature of 0 °C. Capacity at evaporating temperature of -10 °C is approx. 85kW.


2 in stock
Cooling capacity:
165 kW/49 tons
Number of cooling circuits:
1
Type of refrigerant:
R134A
Voltage:
400 V
Absorbed power:
57,4 kW
Year of Manufacture:
2014
Dimensions (LxWxH):
307 x 130 x 228 cm
Weight (kg):
1.741 kg


Foto 1-15-173kW vriesinstall.jpg
Foto 1-15-173kW vriesinstall.jpg Foto 2-13-173kW vriesinstall.jpg Foto 3-7-173kW vriesinstall.jpg Foto 4-5-173kW vriesinstall.jpg nixel.gif

Description / remarks:

Used Bitzer Freeze package type 3 x HSN 7471-75. This Freeze package which is in very good condition, is equipped with the following main components:

  • Frame built for indoor installation 3 piece HSN 7471-75 screw compressors, oil separator, oil filters, under cooler connected to the eco's of the compressors, liquid receiver.
  • Separate control box with frequency control for the compressors.
  • Separate air-cooled condenser of your choice.
  • Freeze package will be tested after sale in our test room and a full test report will be supplied with a 3 months guarantee.

Mention colling capacity of 173kW is with refrigerant R507 at -40°C / +40°C / ECO.


Cooling capacity:
173 kW/50 tons
Number of cooling circuits:
1
Type of refrigerant:
R507
Voltage:
400 V
Absorbed power:
165 kW
Year of Manufacture:
2008
Dimensions (LxWxH):
420 x 170 x 240 cm
Weight (kg):
3.500 kg


Grasso-GEA FX PP 2x650d used freeze pump-instal.-1.jpg
Grasso-GEA FX PP 2x650d used freeze pump-instal.-1.jpg Grasso-GEA FX PP 2x650d used freeze pump-instal.-6.jpg Grasso-GEA FX PP 2x650dused freeze pump-installat.260KW 2.jpg Grasso-GEA FX PP 2x650d used freeze pump-instal.-4.jpg Grasso-GEA FX PP 2x650d used freeze pump-instal.-5.jpg

Description / remarks:

Used Grasso/GEA freeze-pump installation. This in very good maintained condition freeze-pump installation will be composed of the following main components by Comron International:



The mentioned cooling capacity of 260kW is with refrigerant R717/ammonia at -40°C/+35°C and the capacity with 60Hz 3600 rpm will be 310kW.


Cooling capacity:
260 kW/76 tons
Type of refrigerant:
R717/Ammonia
Voltage:
50Hz/60Hz 400V/460 V
Absorbed power:
240 kW
Year of Manufacture:
2006/2023


373kw.20171214_155645_resized_2.jpg 373kw.20171214_155817_resized_2.jpg 373kw.com.IMG_4333.jpg 373kw.com.IMG_4334.jpg 373kw.com.IMG_4335.jpg

Description / remarks:

Used complete Bitzer / Helpman cooling installation for processing rooms and or corridors. This in very good maintained condition cooling installation consists of the following main components:

  • Bitzer cooling plant (built in a 10 ft container for outdoor installation), equipped with 3 pieces 6F-50.2Y compressors, oil separator, switch-board, liquid tank
  • Helpman / Alfa-Laval air-cooled condenser type HTC-100-253-410-CT-400V
  • 14 pieces Helpman double-sided evaporators type Thor-D-436-7-L-42 / 5-220V
  • P&ID drawing and the necessary certificates

Mentioned cooling capacity is at an evaporating temperature of 0 ° C.


Cooling capacity:
373 kW/110 tons
Number of cooling circuits:
1
Type of refrigerant:
R507
Amount of refrigerant / circuit:
550 kg
Voltage:
400 V
Absorbed power:
151 kW
Year of Manufacture:
2005


Foto1IMG_4608 NH3heat-Vriespomp Instal.456kw.jpg
Foto1IMG_4608 NH3heat-Vriespomp Instal.456kw.jpg Foto-2 IMG 4618 CO2-1-Vriespomp Instal.456kw.jpg Foto3-IMG_5532-Vriespomp Instal.456kw.jpg FotoGrasso4-MR-M2655S-2-1-Vriespomp Instal.456kw.jpg Foto5-IMG_0083-Vriespomp Instal.456kw.jpg

Description / remarks:

Used CO2 Grasso/GEA industrial freeze pump installation. This in very good condition CO2 freezing pump installation with a cooling capacity of approx. 456 kW at -40°C/ +35°C and consist of the following main components:

  • 3 pieces Grasso/GEA 35 HP piston compressors R744/CO2, capacity 152 kW at -40°C / -10°C piston packaging equipped with:
    - Meter set
    - Oil separator
    - All safety switches
    - E-motor ROAD 45kW / 400V / 50Hz / 1475 RPM – 440V / 60Hz / 1770 RPM
  • GEA/Grasso MB-5BFU high pressure screw package existing  from:
    - 200 kW E-motor / year of manufacture 2015
    - Oil separator
    - Thermosiphon
    - Oil cooler shell and tube type Grasso
    - Siemens PLC controller
  • Tranter Cascade exchanger / type SPW-075-H-08-348-1-1-W Mantel shell: Ammonia
    Plates: CO2 capacity 800 kW at -6°C condensing.
  • Low pressure separator CO2(-45/-40°C surge drum)m³. To be delivered new by Comron International BV complete with 2 pieces of CO2 hermetic liquid pumps and all necessary valves and safety switches.
  • Low pressure separator ammonia (-10°C surge drum) brand Polar with a capacity of 2m³ for natural ammonia circulation year of manufacture 2004.
  • Evapco evaporative condenser type ATC-M252-TG built in 2010 complete with water pump 2.2 kW, water heaters, heating element. Capacity with a condensation temperature of +35°C/wet bulb +22°C is 944kW High pressure liquid tank brand Romer 1,100 liters / year of manufacture 2010.
  • Witt high-pressure float.
  • Complete custom-made control cabinet with new wiring.
    - New Siemens PLC with touch screen type 1200.
    - Frequency converter for the 200 kW E-motor of the Gea/Grasso high pressure screw package
    - Custom made software for the whole installation.
  • Installation comes with all necessary pressure certificates.
  • All requested valves, Danfoss control stations, floaters, P&ID drawings.
  • Mentioned cooling capacity is with the refrigerant CO2/Ammoniac
    CO2 -40/-10 NH3 -10/+35

Cooling capacity:
456 kW/134.11 tons
Type of refrigerant:
CO2/R717
Voltage:
400 V
Absorbed power:
290 kW
Year of Manufacture:
2011/2015


IMG_1886-Vriespompinst. 466kw.jpg
IMG_1886-Vriespompinst. 466kw.jpg IMG_1872-Vriespompinst. 466kw.jpg IMG_1883-Vriespompinst. 466kw.jpg IMG_1891-Vriespompinst. 466kw.jpg IMG_6206-Vriespompinst. 466kw.jpg

Description / remarks:

Used and in very good maintained condition complete Howden freezing-pump installation. This, complete freezing-pump installation has been composed of the following main components by Comron International:

  • 2 pieces Howden screw compressors/package, compressor type MK6B/WRV20414550/679
  • Each screw package/unit equipped with Leroy-Somer 200kW E-motor, water-cooled shell&tube oil cooler, vertical oil separator, oil pump, closed intercooler eco, control box with new Siemens S7 PLC/Simatic touchscreen
  • Low pressure separator -40°C brand Cofrin volume 3,5m3 built on frame with 2 pieces Hermatic CAM 2/3 ammonia liquid pumps
  • High pressure liquid tank brand Cofrin volume 1,5m3
  • Oil cooling through a Baltimore cooling tower type VFL 241 HXR
  • Evapco evaporating condenser type LSCB-185
  • Custom made switch-box with new Siemens S7 PLC/Simatic touchscreen, Siemens soft starters for the 200kW E-motors and new software
  • All requested valves, Danfoss control stations, floaters, P&ID drawings, E-drawings and PED pressure certificates

Mentioned cooling capacity is with the refrigerant R717 at-40°C /+35°C with eco, absorbed power approx.. 350kW.



This installation is very suitable for all types of spiral, tunnel, IQF, flow, blast, plate & belt freezers.


Cooling capacity:
466 kW/137.05 tons
Type of refrigerant:
R717/Ammonia
Voltage:
400 V
Absorbed power:
350 kW
Year of Manufacture:
2006


DSCN6786.JPG DSCN6785.JPG DSCN6788.JPG DSCN4972.JPG DSCN4989.JPG

Description / remarks:

Used, in very good maintained condition Gram/Frick complete freezing pump installation and consists of the following main components:

  • 1 x Gram GSVII-111 screw package (year 1998) with a 250kW Schorch E-motor
  • 1 x Gram GSV-147 screw package (year 2002) with a 250kW Leroy Somer E-motor
  • Each screw package equipped with:
    Oil separator
    Oil cooler
    Gram processor
  • Vertical low pressure separator -40°C, volume 6m3
  • Eco tank, volume 482 Liters
  • High pressure tank
  • Air-cooled condenser (If desired, it can be also delivered with an evaporating condenser)
  • Switch-board cabinet with Siemens PLC

Mentioned cooling capacity of 500kW is with the refrigerant R717/ammonia at -40°C /+30°C.


Cooling capacity:
500 kW/147 tons
Type of refrigerant:
NH3 Ammonia
Voltage:
380 V
Absorbed power:
320 kW
Year of Manufacture:
1998/2002


Grasso-GEA FX PP20 2x2 650duo used reeze pump-instal. 520kWPic1.jpg
Grasso-GEA FX PP20 2x2 650duo used reeze pump-instal. 520kWPic1.jpg Grasso-GEA FX PP20 2x2 650duo used reeze pump-instal. 520kWPic2.jpg Grasso-GEA FX PP20 2x2 650duo used reeze pump-instal. 520kWPic3.jpg Grasso-GEA FX PP20 2x2 650duo used reeze pump-instal. 520kWPic4.jpg Grasso-GEA FX PP20 2x2 650duo used reeze pump-instal. 520kWPic5.jpg

Description / remarks:

Used Grasso/GEA freeze-pump installation. This in very good maintained condition freeze-pump installation will be composed of the following main components by Comron International:



The mentioned cooling capacity of 520 kW is with refrigerant R717/ammonia at -40°C/+35°C and the capacity with 60Hz 3600 rpm will be 620 kW.


Cooling capacity:
520 kW/152.94 tons
Type of refrigerant:
R717/Ammonia
Voltage:
50Hz/60Hz 400V/460 V
Absorbed power:
450 kW
Year of Manufacture:
2006/2023


IMG_2880-560kw.Vriesbewaarinst.jpg IMG_2897-560kw.Vriesbewaarinst.jpg IMG_2900-560kw.Vriesbewaarinst.jpg IMG_2790-560kw.Vriesbewaarinst.jpg IMG_2876-560kw.Vriesbewaarinst.jpg

Description / remarks:

Used industrial cooling/freezing installation brand Grasso / GEA / Baltimore. This fine and very well maintained cooling/freezing installation with a capacity of 560 kW (840 kW with 3 compressors) -6°C/CO2 and 150 kW -33°C/CO2is composed of the following main components:

  • 3 pieces NH3 Grasso/GEA  direct driven piston compressors type V 600 of which 1 stand-by, each equipped with ABB 100kW E-motor frequency-controlled, latest GEA controller. Capacity each compressor is 365kW at -8°C/+32°C with an absorbed power 79kW.
  • 2 pieces Baltimore hybrid evaporating condensers type CXVE 151 0809-10L. Capacity each condenser is 547kW at wet bulb temp. of +21°C and condensation temp. of +32°C.
  • Hansen Air Purger.
  • Horizontal -10°C NH3 separator, internally connected to the cascade CO2 condenser with natural CO2circulation -6°C.
  • Horizontal -6°C COliquid separator complete with 2 pieces hermetic CO2 liquid pumps.
  • Oil equalizer tank (collection system) connected to the NH3 separator with automatic return system.
  • -33°C COfrozen storage plants 150 kW with 3 pieces Dorin CO2 piston compressor -33°C/-6°C.
  • 10 pieces Coolers and Condensers evaporators type pump circulation CO2, equipped with 3 pieces ventilators (3 x 0,39kW), hot glycol defrosting. Capacity is 33 kW at evaporating temp. of -4°C at air inlet temp. of +2°C.
  • 6 pieces Coolers and Condensers evaporators type pump circulation CO2, equipped with 2 pieces ventilators (2 x 1,77kW), hot glycol defrosting. Capacity is 38 kW at evaporating temp. of -4°C at air inlet temp. of +2°C.
  • 4 pieces Coolers and Condensers evaporators type pump DX CO2, equipped with 2 pieces ventilators (2 x 0,6kW), electric defrosting. Capacity is 17,5 kW at evaporating temp. of -31°C at air inlet temp. of -25°C.
  • Switchboard cabinet with Siemens S7/Simatic touchscreen, Danfoss frequency controller for the 3 pieces Grasso/GEA compressors and the fans of the Baltimore condensers.

Cooling capacity:
560 kW/164.7 tons
Type of refrigerant:
R717/CO2
Voltage:
400 V
Year of Manufacture:
2015


Foto 1-Mycom-Mayekawa Ammvriesp. install570kw.jpg
Foto 1-Mycom-Mayekawa Ammvriesp. install570kw.jpg Foto 2-Mycom-Mayekawa Ammvriesp. install570kw.jpg Foto 3-Mycom-Mayekawa Ammvriesp. install570kw.jpg Foto 4-Mycom-Mayekawa Ammvriesp. install570kw.jpg nixel.gif

Description / remarks:

Used complete Mycom/Mayekawa freeze pump installation. This ammonia freezing installation, which is in new condition, is composed by the company Comron International BV of the following main components:

  • 3 pieces complete Mycom/Mayekawa screw package type 200VMD, year 2002. E-motor 200 kW Leroy Somer, thermosiphon oil cooler, eco connection, and new Siemens S7 PLC/Simatic touchscreen.
  • Switch cabinet if desired at extra costs with 3 pieces new frequency regulators and  new Siemens S7 PLC/Simatic touchscreen.
  • New low-pressure separator -40°C (surge drum) with a volume of 3 m³ with 2 pieces of ammonia liquid pumps.
  • New eco vessel -10°C with a volume of 1m³.
  • High pressure liquid tank for thermosiphon application.
  • Custom-made software for the control of the entire system.
  • Baltimore / Evapco evaporative condenser of your choice.
  • All necessary valves, floaters, electronic liquid regulators, Danfoss valves, for the complete installation.
  • All necessary P&ID drawings, E-schemes and PED pressure certificates.

Mentioned cooling capacity of 570kW is with the refrigerant NH³ at -40 °C / +35°C. Cooling capacity on 60Hz at 3600 RPM = Aprox.695 kW.


Cooling capacity:
570 kW/167 tons
Type of refrigerant:
R717/Ammonia
Voltage:
50/60Hz - 400V / 460 V
Absorbed power:
Ca. 409 kW
Year of Manufacture:
2002/2025


IMG_0086-cooling plant-581kw.jpg
IMG_0086-cooling plant-581kw.jpg IMG_0073-cooling plant-581kw.jpg IMG_0051-cooling plant-581kw.jpg IMG_0072-cooling plant-581kw.jpg IMG_0061-cooling plant-581kw.jpg

Description / remarks:

Used and in condition as new (only 1150 hours in production) complete Bitzer cooling installation consists of the following main components:

  • Bitzer cooling plant (built in an isolated container for outdoor application ) equipped with:
    3 pieces Bitzer screw packages type HSK 7461-80, each package with 63 kW E-motor, oil filter, low-/high pressure gauges, low-/ high pressure switch,
    Central oil separator
    Vahterus heat exchanger type PHSE-3LL-108-1/1 for liquid subcooling
    Complete control cabinet
  • Central liquid vessel
  • Evapco evaporating condenser type ATC-M252E with frequency controlled fan motor
  • Refrigeration and electrical drawings

Mentioned cooling capacity of is with the refrigerant R404a at -3°C/ +35°C with an absorbed power 154 kW. Cooling capacity at -10°C / +35°C is 435 kW.


Cooling capacity:
581 kW/170.88 tons
Type of refrigerant:
R404A/All Freon
Voltage:
400 V
Year of Manufacture:
2011
Dimensions (LxWxH):
610 x 270 x 255 (container) cm


IMG_0126a.jpg IMG_0128a.jpg IMG_0134a.jpg IMG_0142a.jpg IMG_0143a.jpg

Description / remarks:

Used in very good maintained condition Gram/Frick industrial freezing pump installation and consists of the following main components:

  • 2 x low pressure Frick screw packages, type TDSH 233S and type GSVII 147, year 2003, (cooling capacity at -40°/-12°C is 600 kW)
  • Each low pressure screw package equipped with:
         Leroy Somer E-motor of 90 kw
         New Siemens PLC / Simatic touchscreen
  • 2 x high pressure Frick screw packages, type TDSH 163L and type GSVII-64, year 2003 (cooling capacity at -12°/+42°C is 750 kW)
  • Each high pressure screw package equipped with:
         Leroy Somer E-motor of 160 kw
         New Siemens PLC / Simatic touchscreen
  • All screw packages are equipped with water/glycol oil coolers, plate type
  • Switch-board with Siemens S7 controller
  • Stahlbau low pressure / medium pressure separators -40°C/-12° combined, 4,8m3/3,6m3 volume, complete with 2 pieces Hermetic cam 2/3 liquid pumps, motor 1,5kW
  • Güntner (water/glycol) air-cooled oil cooler (for outside application) is connected to the water-cooled oil coolers of the compressors
  • 2 x Güntner AGV-H10132x5S (D) air-cooled condensers, each 410 kW at condensing temp. +42°C (If desired, it can be also delivered with an evaporating condenser)
  • All TüV certificates

Mentioned cooling capacity of 600kW is with the refrigerant R717 at-40°C /+35°C.


Cooling capacity:
600 kW/176 tons
Type of refrigerant:
NH3/Ammonia
Voltage:
380 V
Absorbed power:
500 kW
Year of Manufacture:
1998 / 2003


Foto 1-Mycom-Mayekawa Ammon. vriesp. install 683kw.jpg
Foto 1-Mycom-Mayekawa Ammon. vriesp. install 683kw.jpg Foto 2-Mycom-Mayekawa Ammon. vriesp. install-683ks.jpg Foto 3-Mycom-Mayekawa Ammon. vriesp. install-683kw.jpg Foto 4-Mycom-Mayekawa Ammon. vriesp. install-683kw.jpg Foto 5-Mycom-Mayekawa Ammon. vriesp. install-683kw.jpg

Description / remarks:

Used complete Mycom/Mayekawa freeze pump installation. This ammonia freezing installation, which is in new condition, is composed by the company Comron International BV of the following main components:

  • 1 piece complete Mycom/Mayekawa screw package type 200VLD, year 2012. E-motor 315kW WEG, thermosiphon oil cooler, eco connection and new Siemens S7 PLC/Simatic touchscreen.
  • 2 pieces complete Mycom/Mayekawa screw package type 200VMD, year 2012. E-motor 315kW WEG, thermosiphon oil cooler, eco connection, and new Siemens S7 PLC/Simatic touchscreen.
  • Switch cabinet brand Schneider with 2 pieces frequency regulators for the compressor type 200 VMD and 1 piece soft starter for the compressor type 200 VMD, new Siemens S7 PLC/Simatic touchscreen.
  • New low-pressure separator -40°C (surge drum) with a volume of 3.5 m³ with 2 pieces of ammonia liquid pumps.
  • New eco vessel -10°C with a volume of 1m³.
  • High pressure liquid tank for thermosiphon application.
  • Custom-made software for the control of the entire system.
  • 1 piece Baltimore / Evapco evaporative condenser of your choice.
  • All necessary valves, floaters, electronic liquid regulators, Danfoss valves, for the complete installation.
  • All necessary P&ID drawings, E-schemes and PED pressure certificates.

Mentioned cooling capacity of 683kW is with the refrigerant R717/Ammonia at -40 °C / +35°C of which 2 pieces of Mycom compressors type 200 VMD run at 60 Hz at 3600RPM.
Cooling capacity with an extra frequency controller for the compressor Mycom 200 VLD = 730 kW.


Cooling capacity:
683 kW/200 tons
Type of refrigerant:
R717/Ammonia
Voltage:
50/60Hz - 400V / 460 V
Absorbed power:
Ca.500 kW
Year of Manufacture:
2012/2015


IMG_1757-Cas. Koelcentrale-3828kw.jpg
IMG_1757-Cas. Koelcentrale-3828kw.jpg IMG_1760-Cas. Koelcentrale-3828kw.jpg IMG_1761-Cas. Koelcentrale-3828kw.jpg IMG_3329-Cas. Koelcentrale-3828kw.jpg IMG_4838-Cas. Koelcentrale-3828kw.jpg

Description / remarks:

Used NH3/CO2 cascade cooling plant. This, in condition as new industrial NH3/CO2 cascade cooling plant is engineered and delivered by the company ENGIE to a large chicken meat producer in the Netherlands. Baseline condition of this cooling plant: to cool down 2.700 pieces broilers of 2 kg from ±32°C to a core temperature of ±4°C in 1 hour. This industrial NH3/CO2 cooling plant is composed of the following main components:

  • 1 piece Pomar horizontal NH3 separator/vessel -11°C, 770dm3, 5000 kW coupled to 3 pieces CO2 Alfa-Laval condensers type plate, capacity at -11°C/-7°C is 1250kW per condenser.
  • 1 piece Pomar CO2 liquid vessel/separator -10°C, 9600dm3, 3750kW complete with 3 pieces  Lederle Hermetic CO2 liquid pumps type CNF, 21 m3/h, built on frame construction
  • 42 pieces Kelvion/Goedhart cooling evaporators type PLK, of which:
    21 pieces with 5 fans 2.2 kW installed power per fan
    21 pieces with 6 fans 2.2 kW installed power per fan , fin space 10mm, air direction blowing vertically downwards (if desired air direction blowing horizontally), material Cu/Al seawater resistant, defrosting through air (hot gas defrost possible).
  • Alfa-Laval plate heat exchanger 225 kW at water inlet/outlet temp. of +18°C/+24°C coupled to the glycol line of the oil coolers compressors
  • Custom-made control/switch cabinets with Siemens S7-300 PLC/touch screen (at extra cost).
  • Mycom/Mayekawa heat pump installation with a maximum outlet water temp. of 69°C, consists of 1 piece piston compressor package type N6HS frequency controlled with Siemens IP55 315kW E-motor, heating capacity is 1678kW (at extra cost).
  • All necessary pressure certificates, original books and electrical drawings.

Note: At an additional cost, we can supply it with a complete compressor installation with brands such as Grasso, Mycom, Howden, or Sabroe.


Cooling capacity:
3828 kW/1125.88 tons
Type of refrigerant:
NH3/CO2
Voltage:
400 V
Absorbed power:
1347 kW
Year of Manufacture:
2018

Comron Used To Cool
